1. Dimensions: 12400*2500*3680mm
2. Curb mass:8000kg; total mass:40000kg; rated load: 32000kg; rear wheel track: 1820mm; steel structure:Q550(better than Q345B); girder height:500mm; upper flange thickness:12mm; web thickness:6mm; base board thickness:14mm; side board height:800mm. The box-stake adopts rectangular tube.
3. Attached original parts:traction pin 90mm,Fuwa axle:3*13 tons; tire:11.00R20;dual-air chamber;leaf spring:
4. Accessory:tool box, quantity 1; spare tire rack, quantity 2.
