S/N

Descriptions

Specification

1

Semi-trailer framework upper flange plate thickness

12mm (Manganese steel)

2

Semi-trailer framework bottom flange plate thickness

8mm（Manganese steel）

3

Semi-trailer framework lower flange plate thickness

16mm（Manganese steel）

4

Bearing part bottom flange plate thickness

280mm

5

Bearing part high end thickness

350-480mm

6

Tire

    12.00R20R

7

Axle

Fuwa axle

8

28T Tieli supporting leg

9

Traction pin

90＃

10

Tank body case thickness

10mm aluminium sheet

11

Total mass

40000

12

Rated mass

28000

13

Curb mass

12000

14

Wheel base/ number of axle

6690+1305+1305

15

External dimensions

11000×2495×3800

16

Tank body dimensions

10700*2480*2050

17

Number of compartment

5

18

Number of leaf spring

-/8/8/8

19

Approach angle/departure angle

-/19

20

Effective volume

40 cubic meters

21

Discharge opening device

Sea suction valve shall be mounted at the lower part of the tank, and one gravitational flow opening shall be mounted for the left and right tail section.

22

Remarks

1 warranty manual; 1 service station directory;

1 instruction manual; 1 set of vehicle tool:

1 spare tire; 1 toolbox;

1 ladder; 1 sign board
